Key Specifications
Form Factor: ATX
CPU Socket / Support: Intel LGA1851 / Intel Core Ultra Processors Series 2
Chipset: Intel Z890
Memory Support: 4 × DDR5 DIMM slots, up to 256GB; up to DDR5-9066+ (OC); Intel XMP 3.0 and CUDIMM support
Expansion Slots: 1 × PCIe 5.0 x16 / 2 × PCIe 4.0 x4 / 1 × PCIe 4.0 x1
Storage Support: 1 × PCIe Gen5 x4 M.2 / 2 × PCIe Gen4 x4 M.2 / 1 × PCIe Gen4 x4 & SATA M.2 / 4 × SATA3
Graphics Output: 1 × HDMI 2.1 / 1 × DisplayPort 1.4 / 1 × Thunderbolt 4 / USB4 Type-C display output
Networking: 2.5Gbps LAN / Wi‑Fi 6E / Bluetooth 5.3
Audio: Realtek ALC897 7.1-channel HD audio
USB Connectivity:
Rear: 1 × Thunderbolt 4 / USB4 Type-C, 1 × USB 3.2 Gen2x2 Type-C, 1 × USB 3.2 Gen2 Type-A, 2 × USB 3.2 Gen1 Type-A, 4 × USB 2.0;
Front: 1 × USB 3.2 Gen2x2 Type-C, 4 × USB 3.2 Gen1 Type-A, 4 × USB 2.0
Power Design: 16+1+1+1+1 power phase design with Dr.MOS
Dimensions: 30.5 × 24.4 cm
Additional Information
Cooling / Heatsinks: Enlarged heatsink armour, intelligent cooling design, M.2 heatsinks
RGB / Lighting Support: 1 × RGB LED header / 3 × addressable LED headers; ASRock Polychrome RGB / SignalRGB support
DIY / Convenience Features: BIOS Flashback, Auto Driver Installer, Post Status Checker
Special Features: Thunderbolt 4 / USB4, Memory OC Shield, reinforced PCIe 5.0 slot, 2oz copper PCB
Compatibility Notes: Display outputs require a processor with integrated graphics. Wi‑Fi 6E’s 6GHz band requires Windows 11 and a compatible 6GHz router.
WARRANTY: 3 YEARS
