Key Specifications
Form Factor: ATX
CPU Socket / Support: AMD AM5 / AMD Ryzen 9000, 8000 and 7000 Series Processors
Chipset: AMD X870
Memory Support: 4 × DDR5 DIMM slots, up to 256GB; up to DDR5-8000+ (OC); Intel XMP / AMD EXPO support
Expansion Slots: 2 × PCIe 5.0 x16 supporting x16 or x8/x8 / 1 × PCIe 3.0 x16-length slot operating at x4
Storage Support: 2 × PCIe Gen5 x4 M.2 / 1 × PCIe Gen4 x4 M.2 / 1 × PCIe Gen3 x4 M.2 / 4 × SATA3
Graphics Output: 1 × HDMI 2.1 / 2 × USB4 Type-C display outputs
Networking: 1 × 10Gbps LAN / 1 × 5Gbps LAN / Wi‑Fi 7 / Bluetooth 5.4
Audio: Realtek ALC4082 7.1-channel HD audio with Nahimic Audio
USB Connectivity:
Rear: 2 × USB4 Type-C, 2 × USB 3.2 Gen2 Type-A, 6 × USB 3.2 Gen1 Type-A, 2 × USB 2.0;
Front: 1 × USB 3.2 Gen2x2 Type-C, 4 × USB 3.2 Gen1 Type-A, 6 × USB 2.0
Power Design: 18+2+1 power phase design with 80A SPS
Dimensions: 30.5 × 24.4 cm
Additional Information
Cooling / Heatsinks: Enlarged heatsink armour, advanced thermal design, XXL M.2 heatsink, M.2 bottom heatsink
RGB / Lighting Support: 1 × RGB LED header / 3 × addressable LED headers; ASRock Polychrome RGB / SignalRGB support
DIY / Convenience Features: BIOS Flashback, Auto Driver Installer, flexible integrated I/O shield, graphics-card EZ Release, toolless M.2 heatsink, Dr. Debug, onboard power and reset buttons
Special Features: Dual USB4, dual 10Gbps + 5Gbps LAN, dual PCIe Gen5 graphics slots, dual Gen5 M.2 storage, 8-layer PCB
Compatibility Notes: One Gen5 M.2 slot shares bandwidth with USB4; the Gen3 M.2 slot shares bandwidth with the third PCIe slot. Display outputs require processor-integrated graphics. Wi‑Fi 7 requires Windows 11.
WARRANTY: 3 YEARS
