Key Specifications
Form Factor: ATX
CPU Socket / Support: AMD AM5 / AMD Ryzen 9000, 8000 and 7000 Series Processors
Chipset: AMD X870
Memory Support: 4 × DDR5 DIMM slots, up to 256GB; up to DDR5-8000+ (OC); Intel XMP / AMD EXPO support
Expansion Slots: 1 × PCIe 5.0 x16 / 1 × PCIe 4.0 x16-length slot up to x4 / 2 × PCIe 4.0 x16-length slots operating at x1
Storage Support: 1 × PCIe Gen5 x4 M.2 / 1 × PCIe Gen4 x4 M.2 / 1 × PCIe Gen3 x2 & SATA M.2 / 4 × SATA3
Graphics Output: 1 × HDMI 2.1 / 2 × USB4 Type-C display outputs
Networking: 2.5Gbps LAN / Wi‑Fi 7 / Bluetooth 5.4
Audio: Realtek ALC897 7.1-channel HD audio with Nahimic Audio
USB Connectivity:
Rear: 2 × USB4 Type-C, 2 × USB 3.2 Gen2 Type-A, 1 × USB 3.2 Gen1 Type-A, 4 × USB 2.0;
Front: 1 × USB 3.2 Gen1 Type-C, 4 × USB 3.2 Gen1 Type-A, 4 × USB 2.0
Power Design: 16+2+1 power phase design with 80A Dr.MOS
Dimensions: 30.5 × 24.4 cm
Additional Information
Cooling / Heatsinks: Enlarged heatsink armour, intelligent cooling design, M.2 bottom heatsink
RGB / Lighting Support: 1 × RGB LED header / 3 × addressable LED headers; ASRock Polychrome RGB / SignalRGB support
DIY / Convenience Features: BIOS Flashback, Auto Driver Installer, flexible integrated I/O shield, Post Status Checker
Special Features: Dual 40Gbps USB4 Type-C ports, PCIe Gen5 graphics and storage, 8-layer PCB
Compatibility Notes: The secondary CPU-connected PCIe slot shares bandwidth with USB4; enabling its full x4 mode disables USB4. One M.2 slot disables two SATA ports when occupied. Display outputs require processor-integrated graphics. Wi‑Fi 7 requires Windows 11.
WARRANTY: 3 YEARS
