Key Specifications
Form Factor: Mini-ITX
CPU Socket / Support: Intel LGA1851 / Intel Core Ultra Processors Series 2
Chipset: Intel B860
Memory Support: 2 × DDR5 DIMM slots, up to 128GB; up to DDR5-9333+ (OC); Intel XMP 3.0 and CUDIMM support
Expansion Slots: 1 × PCIe 5.0 x16
Storage Support: 1 × PCIe Gen5 x4 M.2 / 1 × PCIe Gen4 x4 M.2 / 3 × SATA3
Graphics Output: 1 × HDMI 2.1 / 1 × Thunderbolt 4 / USB4 Type-C display output
Networking: 2.5Gbps LAN / Wi‑Fi 6E / Bluetooth 5.3
Audio: Realtek ALC1220 7.1-channel HD audio with Nahimic Audio
USB Connectivity:
Rear: 1 × Thunderbolt 4 / USB4 Type-C, 2 × USB 3.2 Gen2 Type-A, 4 × USB 3.2 Gen1 Type-A, 1 × USB 2.0;
Front: 1 × USB 3.2 Gen2 Type-C, 2 × USB 3.2 Gen1 Type-A, 2 × USB 2.0
Power Design: 10+1+1+1+1 power phase design with 110A SPS
Dimensions: 17.0 × 17.0 cm
Additional Information
Cooling / Heatsinks: Composite VRM heatsink with fan and heat pipe, enlarged heatsink armour
RGB / Lighting Support: 2 × addressable LED headers; ASRock Polychrome RGB / SignalRGB support
DIY / Convenience Features: BIOS Flashback, Auto Driver Installer, flexible integrated I/O shield, Post Status Checker, thermistor header
Special Features: 40Gbps Thunderbolt 4 / USB4, Memory OC Shield, reinforced PCIe 5.0 slot, 10-layer PCB
Compatibility Notes: Display outputs require a processor with integrated graphics. Wi‑Fi 6E’s 6GHz band requires Windows 11 and a compatible 6GHz router.
WARRANTY: 3 YEARS
