Key Specifications
Form Factor: Mini-ITX
CPU Socket / Support: AMD AM5 / AMD Ryzen 9000, 8000 and 7000 Series Processors
Chipset: AMD B850
Memory Support: 2 × DDR5 DIMM slots, up to 128GB; up to DDR5-8200+ (OC); Intel XMP / AMD EXPO support
Expansion Slots: 1 × PCIe 5.0 x16
Storage Support: 1 × PCIe Gen5 x4 M.2 / 1 × PCIe Gen4 x4 M.2 / 2 × SATA3
Graphics Output: 1 × HDMI 2.1 / 1 × rear USB-C DisplayPort Alt Mode output
Networking: 2.5Gbps Killer LAN / Wi‑Fi 6E / Bluetooth 5.2
Audio: Realtek ALC1220 7.1-channel HD audio with Nahimic Audio
USB Connectivity:
Rear: 1 × USB 3.2 Gen2 Type-C, 2 × USB 3.2 Gen2 Type-A, 1 × USB 3.2 Gen1 Type-A, 4 × USB 2.0;
Front: 1 × USB 3.2 Gen1 Type-C, 2 × USB 3.2 Gen1 Type-A, 2 × USB 2.0
Power Design: 10+1+1 power phase design with 110A SPS
Dimensions: 17.0 × 17.0 cm
Additional Information
Cooling / Heatsinks: Intelligent cooling design with enlarged heatsink armour
RGB / Lighting Support: 2 × addressable LED headers; ASRock Polychrome RGB / SignalRGB support
DIY / Convenience Features: BIOS Flashback, Auto Driver Installer, flexible integrated I/O shield, thermistor header
Special Features: PCIe Gen5 graphics and storage, Lightning Gaming Ports, 8-layer PCB; rear USB-C supports up to 40Gbps with selected processors
Compatibility Notes: PCIe/M.2 speeds and rear USB-C bandwidth vary by processor. Display outputs require processor-integrated graphics. Wi‑Fi 6E’s 6GHz band requires Windows 11 and a compatible router.
WARRANTY: 3 YEARS
