Key Specifications
Form Factor: Mini-ITX
CPU Socket / Support: AMD AM5 / AMD Ryzen 9000, 8000 and 7000 Series Processors
Chipset: AMD A620
Memory Support: 2 × DDR5 DIMM slots, up to 128GB; up to DDR5-7200+ (OC); Intel XMP / AMD EXPO support
Expansion Slots: 1 × PCIe 4.0 x16
Storage Support: 1 × PCIe Gen4 x4 M.2 / 1 × PCIe Gen3 x4 M.2 / 2 × SATA3
Graphics Output: 1 × HDMI 2.1
Networking: 2.5Gbps LAN / Wi‑Fi 6E / Bluetooth 5.2
Audio: Realtek ALC897 7.1-channel HD audio with Nahimic Audio
USB Connectivity:
Rear: 1 × USB 3.2 Gen2 Type-C, 2 × USB 3.2 Gen2 Type-A, 1 × USB 3.2 Gen1 Type-A, 2 × USB 2.0;
Front: 1 × USB 3.2 Gen1 Type-C, 2 × USB 3.2 Gen1 Type-A, 2 × USB 2.0
Power Design: 8+2+1 power phase design with 60A Dr.MOS
Dimensions: 17.0 × 17.0 cm
Additional Information
Cooling / Heatsinks: Enlarged heatsink armour
RGB / Lighting Support: 2 × addressable LED headers; ASRock Polychrome RGB support
DIY / Convenience Features: BIOS Flashback, Auto Driver Installer, flexible integrated I/O shield
Special Features: PCIe Gen4 graphics, dual M.2 storage, Lightning Gaming Ports, 8-layer PCB
Compatibility Notes: PCIe and M.2 operation varies by processor. Display output requires processor-integrated graphics. Wi‑Fi 6E’s 6GHz band requires Windows 11 and a compatible router.
WARRANTY: 3 YEARS
