Key Specifications
Form Factor: Micro-ATX
CPU Socket / Support: AMD AM5 / AMD Ryzen 9000, 8000 and 7000 Series Processors
Chipset: AMD B850
Memory Support: 4 × DDR5 DIMM slots, up to 256GB; up to DDR5-8000+ (OC); Intel XMP / AMD EXPO support
Expansion Slots: 1 × PCIe 5.0 x16 / 1 × PCIe 4.0 x4
Storage Support: 1 × PCIe Gen5 x4 M.2 / 2 × PCIe Gen4 x4 M.2 / 4 × SATA3
Graphics Output: 1 × HDMI 2.1 / 1 × DisplayPort 1.4
Networking: 2.5Gbps LAN / Wi‑Fi 6E / Bluetooth 5.2
Audio: Realtek ALC897 7.1-channel HD audio
USB Connectivity:
Rear: 1 × USB 3.2 Gen2 Type-C, 1 × USB 3.2 Gen2 Type-A, 2 × USB 3.2 Gen1 Type-A, 4 × USB 2.0;
Front: 1 × USB 3.2 Gen1 Type-C, 4 × USB 3.2 Gen1 Type-A, 4 × USB 2.0
Power Design: 8+2+1 power phase design with Dr.MOS
Dimensions: 24.4 × 24.4 cm
Additional Information
Cooling / Heatsinks: Intelligent cooling design with M.2 heatsinks
RGB / Lighting Support: 1 × RGB LED header / 3 × addressable LED headers; ASRock Polychrome RGB / SignalRGB support
DIY / Convenience Features: BIOS Flashback, Auto Driver Installer, Post Status Checker, reinforced PCIe 5.0 slot
Special Features: PCIe Gen5 graphics and storage, three M.2 slots, dual HDMI / DisplayPort outputs
Compatibility Notes: Installing an SSD in the CPU-connected secondary M.2 slot disables the PCIe 4.0 x4 slot. PCIe/M.2 speeds vary by processor. Display outputs require processor-integrated graphics. Wi‑Fi 6E’s 6GHz band requires Windows 11 and a compatible router.
WARRANTY: 3 YEARS
