Key Specifications
Form Factor: Micro-ATX
CPU Socket / Support: AMD AM5 / AMD Ryzen 9000, 8000 and 7000 Series Processors
Chipset: AMD B850
Memory Support: 4 × DDR5 DIMM slots, up to 256GB; up to DDR5-8000+ (OC); Intel XMP / AMD EXPO support
Expansion Slots: 1 × PCIe 5.0 x16 / 1 × PCIe 4.0 x16-length slot operating at x4 / 1 × PCIe 4.0 x1
Storage Support: 1 × PCIe Gen5 x4 M.2 / 1 × PCIe Gen4 x4 M.2 / 4 × SATA3
Graphics Output: 1 × HDMI 2.1
Networking: 2.5Gbps LAN / Wi‑Fi 7 / Bluetooth 5.4
Audio: Realtek ALC897 7.1-channel HD audio with Nahimic Audio
USB Connectivity:
Rear: 6 × USB 3.2 Gen1 Type-A, 2 × USB 2.0;
Front: 1 × USB 3.2 Gen1 Type-C, 2 × USB 3.2 Gen1 Type-A, 4 × USB 2.0
Power Design: 8+1+1 power phase design with Dr.MOS
Dimensions: 24.4 × 24.4 cm
Additional Information
Cooling / Heatsinks: Intelligent cooling design
RGB / Lighting Support: 1 × RGB LED header / 3 × addressable LED headers; ASRock Polychrome RGB / SignalRGB support
DIY / Convenience Features: BIOS Flashback, Auto Driver Installer, pre-installed I/O shield, Post Status Checker, toolless SSD installation
Special Features: PCIe Gen5 graphics and M.2 support, Lightning Gaming Ports, white component design
Compatibility Notes: PCIe and M.2 speeds vary by processor. Display output requires processor-integrated graphics. Wi‑Fi 7 requires Windows 11; 6GHz availability varies by region.
WARRANTY: 3 YEARS
