Key Specifications
Form Factor: Micro-ATX
CPU Socket / Support: AMD AM4 / AMD Ryzen 3000, 3000 G-Series, 4000 G-Series, 5000 and 5000 G-Series Desktop Processors
Chipset: AMD A520
Memory Support: 2 × DDR4 DIMM slots, up to 64GB; up to DDR4-4733+ (OC); Intel XMP support
Expansion Slots: 1 × PCIe 3.0 x16 / 1 × PCIe 3.0 x1
Storage Support: 1 × PCIe Gen3 x4 & SATA M.2 / 4 × SATA3
Graphics Output: 1 × HDMI 2.1, up to 4K 60Hz
Networking: Gigabit LAN / Wi‑Fi 5 / Bluetooth 4.2
Audio: Realtek ALC887/897 7.1-channel HD audio
USB Connectivity:
Rear: 4 × USB 3.2 Gen1 Type-A, 2 × USB 2.0;
Front: 2 × USB 3.2 Gen1 Type-A, 4 × USB 2.0
Power Design: 6 power phase design
Dimensions: 23.0 × 20.1 cm
Additional Information
DIY / Convenience Features: ASRock Live Update & APP Shop
Special Features: PCIe Gen3 x4 / SATA M.2 support, HDMI 4K 60Hz, AMD Smart Access Memory, Full Spike Protection
Compatibility Notes: Display output requires a Ryzen processor with integrated graphics. NVMe storage is not supported when using an AMD Athlon 3000G processor.
WARRANTY: 3 YEARS
